solar powered water pump 3 hp

solar powered water pump 3 hp Specification

Input Voltage
DC Input from Solar Panel (110V)

Efficiency
18% (Solar Panel Conversion Efficiency)

Maintenance Type
Minimal, Periodic Cleaning of Panel

Features
Eco-friendly, Low Maintenance, Automatic Operation, Weather-Resistant, High Flow Rate, Overload Protection

Product Type
Solar Powered Water Pump

Material
High-grade Stainless Steel and Polycrystalline Silicon

Number of Cells
72 cells (solar panel array)

Power
3 HP

Operating Temperature
-10C to 50C

Max Voltage
110V (DC) per panel array

Max System Voltage
1000V DC

Output Voltage
DC 110V / AC 220V

Cable Length
20 meters (customizable)

Switch Mode
Automatic/Manual

Size
Standard (customizable based on requirements)

Dimension (L*W*H)
1200 mm x 900 mm x 400 mm (Panel Dimensions)

Color
Blue/Black (Panel), Steel (Pump)

Weight
Approximately 55 kg (System Total)

Type Of Technology
Polycrystalline Silicon Solar

Installation Type
Ground Mount

Compliance Standard
IEC 61701, IEC 61215

Pump Type
Submersible/Centrifugal (Model Specific)

Panel Frame Material
Anodized Aluminum

Service Life
More than 25 years (Panel), 7-10 years (Pump Motor)

Noise Level
<50 dB

Start-up Voltage
70V DC

Motor Type
Brushless DC/AC Motor

Mounting Structure
Hot Dip Galvanized Steel Mounting Frame

Protection Features
Dry Run Protection, Over/Under Voltage Protection

Water Flow Rate
15,000 - 20,000 LPH (Liters Per Hour)

solar powered water pump 3 hp About

T Square Motor is a trusted supplier of high-efficiency Solar Pumps, designed to meet the growing demand for sustainable and cost-effective water pumping in agriculture, domestic, and industrial applications. Our solar pumps run directly on solar energy, reducing electricity costs and enabling off-grid operation in rural areas.

Key Features:

Available in AC and DC pump variants
Power range: 0.5 HP to 10 HP
Submersible and surface pump options
High-efficiency MPPT-based solar controllers for maximum power output
Durable construction with corrosion-resistant stainless steel body
Low maintenance and long service life
Built-in protections: dry run, overload, short circuit, reverse polarity
Optional hybrid operation (solar + grid/diesel)

Product Range:

Submersible Solar Pumps Ideal for deep borewells
Surface Solar Pumps Suitable for open wells, ponds, and rivers
AC/DC Solar Pumps Versatile compatibility with solar inverters/controllers
3 HP, 5 HP, 7.5 HP, and 10 HP variants in stock

Applications:

Agricultural irrigation (drip & sprinkler)
Drinking water supply in rural areas
Livestock watering
Government solar pump subsidy schemes
Water lifting from borewells and wells

Why Choose T Square Motor?

Quality-assured solar pump solutions
Competitive pricing and ready stock
Expert guidance on solar system sizing
PAN India delivery and after-sales support

Go green and power your water needs with the sun.
Contact T Square Motor for high-performance Solar Pumps at the best price

Reliable High-Performance Water Delivery

Designed to supply between 15,000 and 20,000 liters of water per hour, this solar-powered pump brings efficient and reliable water delivery even in remote locations. With a power rating of 3 HP and highly durable stainless steel construction, users benefit from significant water flow with minimal maintenance requirements.

Advanced Protection and Longevity

Equipped with dry run, over/under voltage, and overload protection, the pump system ensures operational safety and long-term reliability. The solar panels meet IEC 61701 and IEC 61215 compliance for robust outdoor performance, guaranteeing more than 25 years of active life, protecting your investment and resource needs.

Versatile and Eco-Friendly Applications

Perfect for agricultural irrigation, drinking water supply, or livestock watering, this pump system operates through eco-friendly solar energy. Ground-mount installation with a galvanized steel frame and an anodized aluminum panel design make it a sustainable, weather-resistant solution for various water supply requirements.

FAQ's of solar powered water pump 3 hp:

Q: How does the solar-powered water pump operate during cloudy weather?

A: The system is designed to function with reduced capacity during cloudy conditions, as solar panels generate less power when sunlight is limited. However, the pump will still operate as long as the minimum start-up voltage (70V DC) is met, ensuring some level of water delivery even in diffused light.

Q: What maintenance is required for this solar water pump system?

A: Maintenance is minimal-primarily periodic cleaning of the solar panels to ensure they're free from dust or debris, which can affect efficiency. Pump and motor components are built for durability, requiring only standard periodic inspections as outlined in the user manual.

Q: When should I use the automatic versus manual switch mode?

A: Automatic mode is ideal for regular water management where minimal supervision is desired. Manual mode can be selected if you need to control specific operations, such as maintenance or emergency shutoff, offering flexibility based on your unique needs.

Q: Where can this system be installed and used?

A: The pump is optimized for ground-mount installation and is highly suitable for agricultural fields, remote farms, livestock areas, and off-grid or sustainable drinking water supply projects. Its weather-resistant, eco-friendly construction allows for versatile and robust outdoor use.

Q: What protection features are included in this water pump system?

A: The pump comes equipped with dry run protection to stop operation when water levels are too low, as well as over and under voltage protection to shield electrical components, ensuring safe and extended operation in various conditions.

Q: How does using this solar pump benefit agricultural operations?

A: It significantly reduces operating costs and environmental impact by harnessing solar energy, providing consistent high flow rates essential for irrigation or livestock, while requiring low maintenance and offering long service life.
