solar powered water pump 5 hp

solar powered water pump 5 hp Specification

Efficiency
18-20% (solar panel)

Features
Eco-Friendly, Low Maintenance, Easy Installation, High Efficiency

Input Voltage
DC 96V/120V/180V (depending on system configuration)

Maintenance Type
Low maintenance

Product Type
Solar Powered Water Pump

Material
Stainless Steel/Metal Body

Number of Cells
72 cells per panel

Power
5 HP

Operating Temperature
-10C to 50C

Max Voltage
45V (per panel)

Max System Voltage
1000V DC

Output Voltage
220V AC/380V AC (depending on configuration)

Cable Length
10-20 meters (customizable)

Switch Mode
Automatic/Manual

Size
Standard (custom sizes available)

Dimension (L*W*H)
Variable, e.g., 1800mm x 1200mm x 400mm (solar panel set)

Color
Blue/Black (panel), Metallic (pump)

Weight
52 kg (approx for panels and pump)

Type Of Technology
Photovoltaic (PV) Solar Technology

Installation Type
Ground Mounted/Self-Standing

Water Output
Continuous during sunlight hours

Panel Type
Mono/Poly Crystalline Silicon

Protection
Overload, Dry Run, Short Circuit, Reverse Polarity

Pump Type
Submersible/Centrifugal

Flow Rate
Up to 80,000 liters per day (varies by head)

Controller Type
MPPT Based Solar Controller

Mounting Structure Material
Galvanized Iron/Aluminum

Maximum Head
Up to 55 meters

solar powered water pump 5 hp About

T Square Motor is a trusted supplier of high-efficiency Solar Pumps, designed to meet the growing demand for sustainable and cost-effective water pumping in agriculture, domestic, and industrial applications. Our solar pumps run directly on solar energy, reducing electricity costs and enabling off-grid operation in rural areas.

Key Features:

Available in AC and DC pump variants
Power range: 0.5 HP to 10 HP
Submersible and surface pump options
High-efficiency MPPT-based solar controllers for maximum power output
Durable construction with corrosion-resistant stainless steel body
Low maintenance and long service life
Built-in protections: dry run, overload, short circuit, reverse polarity
Optional hybrid operation (solar + grid/diesel)

Product Range:

Submersible Solar Pumps Ideal for deep borewells
Surface Solar Pumps Suitable for open wells, ponds, and rivers
AC/DC Solar Pumps Versatile compatibility with solar inverters/controllers
3 HP, 5 HP, 7.5 HP, and 10 HP variants in stock

Applications:

Agricultural irrigation (drip & sprinkler)
Drinking water supply in rural areas
Livestock watering
Government solar pump subsidy schemes
Water lifting from borewells and wells

Why Choose T Square Motor?

Quality-assured solar pump solutions
Competitive pricing and ready stock
Expert guidance on solar system sizing
PAN India delivery and after-sales support

Go green and power your water needs with the sun.
Contact T Square Motor for high-performance Solar Pumps at the best price

High-Performance and Reliable Water Delivery

This solar water pump system delivers efficient and uninterrupted water flow during sunlight hours, with a maximum capacity of 80,000 liters per day. Its robust stainless-steel construction and durable panels ensure reliable use in a variety of demanding settings such as agriculture and remote water supply.

Advanced Technology and Eco-Friendly Solution

Harnessing photovoltaic (PV) solar technology with MPPT-based control, the system achieves superior energy management and high conversion efficiency (18-20%). With built-in protections against overload, dry run, short circuit, and reverse polarity, it safeguards both pump and electrical components.

Flexible Design and Easy Maintenance

Compatible with either submersible or centrifugal pump types, this product comes in customizable sizes with adjustable cable lengths. The ground-mounted or self-standing system is constructed from galvanized iron or aluminum, tailored for easy installation and minimal maintenance, even in challenging environments.

FAQ's of solar powered water pump 5 hp:

Q: How does the solar powered water pump system operate during varying sunlight conditions?

A: The system operates continuously during available sunlight hours by converting solar energy into electrical energy via mono or polycrystalline solar panels. The MPPT controller optimizes power usage, ensuring efficient water output even when sunlight intensity fluctuates.

Q: What type of maintenance does the solar water pump require, and how often should it be performed?

A: This pump features a low-maintenance design, primarily needing occasional cleaning of panels and checks for debris on and around the pump. Routine inspections every few months help maintain optimal performance.

Q: Where can this solar pump system be installed, and what are its ideal applications?

A: This pump is ideal for installation in remote locations, agricultural lands, irrigation setups, and areas lacking reliable grid power. It can be easily set up on ground-mounted or self-standing structures.

Q: What process is involved in installing the solar powered water pump?

A: Installation typically involves mounting the solar panels on a galvanized iron or aluminum structure, connecting the pump via provided cables (customizable up to 20 meters), and configuring the MPPT controller. Professional assistance ensures correct system setup and reliable performance.

Q: What are the main benefits of using this solar water pump compared to traditional pumps?

A: Key benefits include eco-friendly operation with no fuel dependence, low operating costs, high efficiency, protection features for longevity, and suitability for remote off-grid environments. The automatic/manual switch mode offers operational flexibility as well.

Q: How do I choose between a submersible or centrifugal pump type for my requirements?

A: If your water source is a deep well or borehole, a submersible pump is recommended. For surface-level water sources with less depth but higher flow needs, a centrifugal pump offers efficient performance. Selection depends on your site's specific conditions.
