solar powered water pump 1 hp

solar powered water pump 1 hp Specification

Input Voltage
120V - 380V DC (from solar panel array)

Maintenance Type
Low

Efficiency
18% (solar panel), 80% (pump)

Features
Eco-friendly, Low Maintenance, High Flow Rate, Easy Installation

Product Type
Solar Powered Water Pump

Material
Corrosion-resistant Metal and High-Efficiency Silicon Solar Panels

Number of Cells
72 cells (per solar module)

Power
1 HP

Operating Temperature
-10C to 50C

Max Voltage
36-45V (solar panel)

Max System Voltage
1000V DC

Output Voltage
220V AC

Cable Length
10 meters (customizable)

Switch Mode
Automatic/Manual

Size
Standard 1 HP Pump Size

Dimension (L*W*H)
1250mm x 1000mm x 1500mm (with panel stand)

Color
Blue/Black (Pump), Blue (Panel)

Weight
Pump: 28 kg, Panel: 20 kg (each)

Type Of Technology
Photovoltaic (PV) Based

Installation Type
Ground Mounted, Outdoor

Mounting Structure
Galvanized Iron, Anti-rust Coating

Control Panel
Digital Solar Controller with MPPT

Panel Tilt Angle
Adjustable (As per Latitude)

Motor Type
Brushless DC Motor

Noise Level
<65 dB

Flow Rate
40,000 L/day (average sunlight hours)

Remote Monitoring
Optional via GSM Module

Maximum Water Output
13,000-17,000 Liters per hour (Depending on sunlight and head)

Application Suitability
Borewell, Open Well, Surface Pumping

Inverter Type
Solar Pump Inverter (Integrated)

Connector Type
MC4 Compatible

Discharge Head
Up to 45 meters

Panel Output Power
Up to 1200 Wp (Watts Peak)

Suction Head
Up to 7 meters

Life Expectancy
25 Years (Solar Panel), 8-10 Years (Pump)

System Autonomy
Operates in Direct Sunlight, Battery-less

Protection
Overload, Dry Run, Overcurrent

solar powered water pump 1 hp About

T Square Motor is a trusted supplier of high-efficiency Solar Pumps, designed to meet the growing demand for sustainable and cost-effective water pumping in agriculture, domestic, and industrial applications. Our solar pumps run directly on solar energy, reducing electricity costs and enabling off-grid operation in rural areas.

Key Features:

Available in AC and DC pump variants
Power range: 0.5 HP to 10 HP
Submersible and surface pump options
High-efficiency MPPT-based solar controllers for maximum power output
Durable construction with corrosion-resistant stainless steel body
Low maintenance and long service life
Built-in protections: dry run, overload, short circuit, reverse polarity
Optional hybrid operation (solar + grid/diesel)

Product Range:

Submersible Solar Pumps Ideal for deep borewells
Surface Solar Pumps Suitable for open wells, ponds, and rivers
AC/DC Solar Pumps Versatile compatibility with solar inverters/controllers
3 HP, 5 HP, 7.5 HP, and 10 HP variants in stock

Applications:

Agricultural irrigation (drip & sprinkler)
Drinking water supply in rural areas
Livestock watering
Government solar pump subsidy schemes
Water lifting from borewells and wells

Why Choose T Square Motor?

Quality-assured solar pump solutions
Competitive pricing and ready stock
Expert guidance on solar system sizing
PAN India delivery and after-sales support

Go green and power your water needs with the sun.
Contact T Square Motor for high-performance Solar Pumps at the best price

High-Performance Solar Pumping Solution

Leverage sunlight to achieve reliable water delivery with this 1 HP solar water pump, boasting a high flow rate of up to 17,000 liters per hour (depending on sunlight and head). The brushless DC motor ensures efficient, low-noise operation, while automatic and manual switch modes add flexibility. Designed for agricultural fields, gardens, and livestock watering anywhere off-grid.

Durable and Smart Construction

The galvanized iron mounting structure with an anti-rust coating and corrosion-resistant components ensure enduring performance in outdoor conditions. The system integrates a digital solar controller with MPPT for maximum energy harvest and operational safety through overload, dry run, and overcurrent protection. Panel tilt is adjustable to suit your latitude, maximizing efficiency year-round.

Eco-friendly, Battery-Free Operation

By operating directly from sunlight without the need for batteries, this pump system reduces running costs and environmental impact. Maintenance is minimal thanks to high-quality photovoltaics and robust design, offering reliable water supply for irrigation and daily agricultural use. Remote monitoring via optional GSM allows for enhanced control and peace of mind.

FAQ's of solar powered water pump 1 hp:

Q: How does the solar-powered water pump operate without batteries?

A: The system runs directly on solar energy using power generated from its photovoltaic panels during daylight hours. It does not require batteries, making it cost effective, low maintenance, and ideal for regions with reliable sunlight.

Q: What are the benefits of using a brushless DC motor in this pump?

A: A brushless DC motor is highly efficient, produces less noise (below 65 dB), and has a longer operational life due to reduced friction and wear. This ensures consistent performance and fewer maintenance requirements over time.

Q: When is the best time to operate the pump for maximum water output?

A: The pump achieves peak performance during the sunniest parts of the day, typically between late morning and mid-afternoon, when sunlight is strongest. Water output depends on light intensity and the discharge head at any given time.

Q: Where can this solar pump system be installed?

A: This system is suitable for installation in agricultural fields, gardens, borewells, open wells, surface water bodies, and remote locations lacking grid electricity. It is designed for ground mounting in outdoor environments with adequate sunlight exposure.

Q: What is the installation process for this water pump?

A: Installation involves setting up the galvanized iron mounting structure, securing the solar panels at an optimal tilt, connecting the pump, and interfacing the digital controller. MC4 compatible connectors and a 10-meter cable make setup straightforward; professional installation is recommended for best results.

Q: How do safety features enhance the operation of the pump system?

A: Built-in protections against overload, dry running, and overcurrent prevent equipment damage and ensure safe operation. The digital solar controller monitors system performance in real time, reducing maintenance needs and prolonging component life.

Q: What is the expected lifespan and maintenance requirement of this system?

A: Solar panels are rated for 25 years of service, while the pump is expected to last 8-10 years. The system is designed to be low maintenance, requiring only occasional inspections and cleaning to maintain peak efficiency.
